MMF to SMF Fiber Mode Converter
LG-MC-FE-MM85-SM13-40
Product Overview
The fiber mode converter is to convert dual core fiber multi mode 850nm or 1310nm wavelength to single mode fiber wavelength, It has 2 fiber ports, one for MMF port and one for SMF port, SFP slot is optional.
Product Information
Product Details
Description
The fiber mode converter is to convert dual core fiber multi mode 850nm or 1310nm wavelength to single mode fiber wavelength, It has 2 fiber ports, one for MMF port and one for SMF port, SFP slot is optional. The fiber converter supports kinds of data rates 10/100/1000M, 155M/622M/STM-1/STM-4, it also can extend long-range fiber connections, according to any agreement between different datas. The optical receiving and sending module are with good optical character, data transmits steady, and it can work for long time.
Specification
Fiber Interface | Connector type | SC, FC, ST are optional LC by SFP slot via SFP module |
Data rate | 10/100Mbps, 155Mbps, 622Mbps 1000Mbps, 1.25Gbps, 2.5Gbps | |
Wavelength | MM: 850nm or 1310nm SM: 1310nm or 1550nm | |
Fiber category | Multi-mode: 50/125um, 62.5/125um Single-mode: 9/125um | |
Transmission distance | MM: up to 2km SM: up to 120km | |
Power supply | Input DC5V, come with AC/DC power adapter Option I: DC-48V, range DC-36V~DC-72C Option II: AC220V, range AC100V~AC240V | |
Power Consumption: ≤3W | ||
Power adapter standard: EU, US, UK (option) | ||
Environment condition | Operating temp: 0℃~+55℃ Storage temp: -45℃~+80℃ Relative temperature: 95% (uncondensed) | |
Dimension | 95mm (L) × 70mm (W) × 26mm (H) | |
Approvals | FCC Part15, CE, RoHS | |
Ordering Information
| Model | Name | Status | Action |
|---|---|---|---|
| LG-MC-FE-MM85-SM13-40 | MMF to SMF Fiber Mode Converter | In Stock |
